Temperature & Humidity Sensor

Measures in real time the temperature and humidity in ambient air.

Why we need a Temperature &  Humidity Sensor in the farm ?

The main function of the temperature and humidity sensor is to collect information from the environment in real time, including both temperature and humidity.

The advantages of our equipment include : low-power usage design, support for long-term monitoring, easy installation, built-in high-precision sensors, and affordable pricing strategies. It can be widely used in agricultural fields, such as farms, livestock breeding pens, soil management, etc.,

allowing users and managers to quickly obtain accurate proportions of temperature and humidity changes.

Our Temperature & Humidity Sensor is equipped with high-precision sensors and combined with automated detection technology, it can quickly and accurately receive and manage data. It can also be connected to other devices to perform other related operations in response to changes in temperature and humidity to meet all user needs.

What Is The Function Of Temperature & Humidity Sensor ?

How it work ?

The Temperature & Humidity Sensor in the ambient air are collected and measured through the equipment, and converted into digital signals or information output in its required form according to certain rules to meet user needs.

Temperature and humidity data are detected through regulations, and the measurement results are directly sent to the equipment main control center - the gateway by 2.4GHz RF IoT transmission technology, and finally uploaded to the cloud center.

Support users created personal accounts. Users can log in to the system remotely with account ID / Password, and enter the system interface center to browse, to meet the user's remote monitoring needs at any time, grasp real-time on-site data or track relevant historical data.

How to operate ?
☑  RF Pairing:sensor and gateway
☑  Choose an appropriate location to install

First install 3 AAA batteries into the device, then perform RF paring, remove the sticker on the back of the device, then select the appropriate location and place the device at the desired measurement location. The device can be used for approximately 9 months.

Installation:
☑  Non-contact detection, collection and data analysis
☑  When the device is operating, it will not affect or interfere with pig activities, nor will it have any contact with pigs.

Setup Instructions:
Temperature measurement:Set-up on an iron pipe in the pig pen, preferably 1.4 meters above the ground.

※ When actually installing and using the product, it must be based on the on-site conditions at the case site.


Applications

• Farm
• Greenhouse
• Environmental Control of Livestock Farms
• Soil Fertilizer Management
• Other Industry Applications

Features

• High-Precision
• Good Linearity
• Good Versatility
• Wide Measurement Range
• Quick Installation and Easy to use
• Low Power Consumption
• Support Long-Term Monitoring

Mobirise

6 Things You Must Know About Temperature & Humidity Sensor

These advantages help improve pig farm management efficiency, ensure pig health, and effectively reduce production costs.

100%

Temperature Control

Humidity Control

Prevent Disease

Growth Benefit

Save Resources

Remote Management

Product Parameters / Specification

Does not cause system burden and maintains quality requirements

Protocol

1

Transmission Technology:IoT 2.4Ghz RF
Data Transfer Capacity:250 kbps
Support:Multi-Channel / Auto Frequency Hopping

Temperature

2

Accuracy:± 0.3℃

Humidity

3

Accuracy:± 2%
Value Range:0 ~ 100%

Working Temperature

4

-10 ~ 50℃

Operating Voltage

5

3.5V DC with 3 AAA Batteries

Service Life

6

‧ With new battery (95% Full), the service life is about 9 months.
‧ When the voltage is low, thr red light will flash as a reminder.
